2400W High-power Water Cooling LED UV Curing System with 18W/CM2 Intensity for UV Ink Drying

Large Image : 2400W High-power Water Cooling LED UV Curing System with 18W/CM2 Intensity for UV Ink Drying

Product Details:

Place of Origin:	China
Brand Name:	CG
Certification:	CE*RoHS
Model Number:	CG-CT3-40027-1500A

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	4000-6200usd 1 set
Packaging Details:	Wooden case
Delivery Time:	10-15 Working days
Payment Terms:	L/C,T/T
Supply Ability:	10 SET/DAY

Contact Now

2400W High-power Water Cooling LED UV Curing System with 18W/CM2 Intensity for UV Ink Drying

Description

Keyword:	LED UV Curing System	Power:	2400W
Input Voltage:	AC85-265V	Wave Length:	395nm
Cooling Way:	Water Cooling	UV Intensity:	18W/CM2
Warranty:	2 Years	Package:	Wooden Case
Highlight:	2400W water cooling LED UV curing system , high-power UV ink drying system , 18W/CM2 intensity LED UV curing

2400W High-power Water-cooled UV Lamps for Wide-width Roll Paper

LED UV Curing System Description

For the drying of UV series materials—be it resin, ink, varnish, adhesive, or coating—the LED UV curing lamp offers a contemporary, high-performance method. This new technology utilizes ultraviolet light to deliver quick, high-quality curing.

LED UV Curing System Datasheet

Model	CG-CT10-1000*50-2400A	Lamp Color	Rose Golden
Power	2400W	Chip Brand	LG/Seoul
Input Voltage	AC85-265V	Wavelength	365/385/395/405nm
Application	UV ink/varnish/coating/adhesive curing	Life Span	20000H
Cooling Way	Water Cooling	Emitting Window Size	Customized
UV Intensity	18W/CM²	Dimmable	0%-100%
Best Emitting Distance	30-50mm	Package	Wooden Case

LED UV Curing System Advantages

Energy-saving - normally 1000W LED UV equals 6000W mercury lamp drying effect
Environment friendly - No mercury, no ozone making and VOC discharge
No warm-up - turn on/off instantly
Low temperature - can be used for PE and film ink curing
Long lifespan - 20,000 hours

Product Details

UV Curing Conveyor Systems FAQ

Q1: What's the wavelength of the LED UV lamp?

A1: Usually 395-405nm. The 395nm/385nm is used for printing machines, 365nm is for adhesive.

Q2: What's your LED brand?

A2: LG/Seoul

Q3: What's the material of lamp and lens?

A3: Aluminium/quartz

Q4: What's the cooling way for the LED UV curing system?

A4: Water or air cooling

Q5: Can the UV intensity be changed?

A5: Yes, the UV intensity is changeable from 0%-100%

Q6: What's the maximum energy of UV LED lamp?

A6: It depends on emitting time - the longer the higher energy output total amount.

Q7: What's the lifespan of the UV LED curing lamp?

A7: Our warranty is 2 years for all system (chiller/power supply), mostly can reach 5 years.
