UV Curing Plastic-to-Glass Bonding Adhesive Medium Viscosity Fast Cure High Strength

UV Curing Plastic-to-Glass Bonding Adhesive

3326 UV Curing Plastic-to-Glass Bonding Adhesive is an amber transparent UV adhesive with medium viscosity and fast curing. It provides good adhesion to glass and various plastics, making it suitable for bonding plastic with plastic, glass and metal, and especially for plastic-to-glass bonding.

Technical Specifications

Key Features

• Medium viscosity for controlled dispensing
• Fast curing for efficient production
• Good adhesion to glass and various plastics
• Bonds plastic with plastic, glass and metal
• Especially suitable for plastic-to-glass bonding
• High hardness and strong bond strength
• Reliable performance on mixed substrates

Applications

• Plastic-to-glass bonding
• Plastic-to-plastic bonding
• Plastic-to-metal bonding
• Bonding of glass and various plastics
• Mixed-substrate assembly requiring high strength

Operation and Curing Guide

1. Surface preparation: clean the surfaces to remove oil, dust and contaminants for maximum adhesion.
2. Dispensing: apply the adhesive evenly to the bonding area.
3. Assembly: position and join the parts, pressing to spread the adhesive and removing any excess before curing.
4. UV curing: expose the adhesive to UV light at 700 mJ/cm² until fully cured.
5. Inspection: verify a uniform bond with no whitening or bubbles.
6. Rework: gently separate bonded parts, clean the surfaces and re-apply the adhesive when repair is needed.

FAQ

Q1: What is the 3326 adhesive mainly used for?
3326 is a UV curing plastic-to-glass bonding adhesive used for bonding plastic with plastic, glass and metal, and especially for plastic-to-glass bonding.

Q2: Does it bond both glass and plastics?
Yes. 3326 provides good adhesion to glass and to various plastics.

Q3: Why is medium viscosity useful?
The medium viscosity gives good control during dispensing for consistent bond lines on mixed substrates.

Q4: How fast does it cure?
3326 cures quickly under UV light at 700 mJ/cm².

Q5: What strength does it provide?
3326 has a Shore D 65 hardness, a tensile strength above 14 MPa and a shear strength of 12 MPa.

Q6: What are the storage conditions and packaging?
Store at 8-28°C in the original sealed container. Shelf Life is 12 months. Available in 1kg and 5kg packaging.
