Earphone UV Fixation Glue Description
"Fix fast, protect joints." This earphone UV fixation glue (3572) is a transparent, fast-curing UV adhesive specially formulated for solder joint protection of TWS earbuds and precision component fixing. It offers high adhesion and high toughness, low shrinkage and low dielectric constant, and high thixotropy with good visibility for convenient dispensing. It cures rapidly under LED or UV light in just 3-5 seconds, making it an ideal choice for high-throughput earphone assembly lines.
Earphone UV Fixation Glue Datasheet
| Model |
3572 UV curing fixation glue |
Packaging specifications |
1kg |
| Brand |
Super-curing |
Cure condition |
600 mJ/cm² (UV / LED) |
| Application |
Earphone solder joint protection and component fixing |
Viscosity (25°C) |
2000±200 mPa·s |
| Substrates |
Plastic and metal parts |
Hardness |
Shore A 50 |
| Color |
Transparent |
Tensile strength |
8 MPa |
| Storage condition |
12 months (8-28°C) |
Elongation at break |
200% |
| Thixotropy |
High, good visibility |
Dielectric constant |
Low |
Product Details Description
Product Applications
- Solder joint protection for TWS earbuds and earphone PCBA
- Fixing of small electronic components in earphone assemblies
- Bonding of plastic and metal parts in earphone assemblies
- Reinforcement of precision electronic assemblies
- Speaker, microphone and battery component fixing
- Applications requiring low shrinkage and low dielectric constant
- High-throughput automated assembly with 3-5s LED curing
- Protection of fine solder joints against vibration and drop impact
Precautions
- Surfaces must be clean, dry and free of oil, dust or flux residues before bonding.
- Apply a suitable bead; avoid excess adhesive around contacts and acoustic openings.
- UV / LED curing requires light to reach the adhesive; shadowed areas may need additional passes.
- Confirm adhesion and cure depth on the actual substrates before mass production.
- Apply in a well-ventilated area. Avoid contact with skin and eyes; wear protective gloves and safety goggles.
- In case of skin or eye contact, rinse immediately with plenty of clean water and seek medical advice if irritation persists.
- Store sealed at 8-28°C in a cool, dark and dry place away from direct sunlight and UV sources, and keep out of reach of children.
FAQ
Q1: What is this earphone UV fixation glue mainly used for?
It is a UV curing fixation glue used for solder joint protection of TWS earbuds and earphones, and for fixing small electronic components in precision assemblies.
Q2: How fast does it cure?
It cures rapidly under LED or UV light in about 3-5 seconds, enabling high throughput on automated earphone production lines.
Q3: What adhesion and toughness does it provide?
It offers high adhesion and high toughness, providing reliable bonding and protection for solder joints and small components.
Q4: Does it have low shrinkage and low dielectric constant?
Yes. It features low shrinkage and a low dielectric constant, making it suitable for precision electronic applications sensitive to stress and electrical performance.
Q5: Is it easy to dispense?
Yes. It has high thixotropy with good visibility, so it dispenses cleanly and stays in place without sagging.
Q6: What are the storage conditions and packaging?
Store sealed at 8-28°C in the original container. Shelf life is 12 months. Available in 1kg packaging with export-grade carton.
