Hydrolyzable UV Adhesive Warm Water Washable Easy Peel for Glass Wafer Temporary Fixing Protection

Hydrolyzable UV Adhesive Warm Water Washable Easy Peel for Glass Wafer Temporary Fixing Protection

Hydrolyzable UV Adhesive is a clear, amber transparent UV-curable adhesive for the temporary fixing and protection of glass wafers. It has strong flow for easy coating and, once UV cured, holds the wafer firmly during grinding, thinning and processing. After processing, it can be hydrolyzed and washed away in warm water, so it peels off easily with no residue and no secondary contamination.

Technical Specifications

Key Features

• Hydrolyzable formula for clean, residue-free removal
• Warm water washable and easy to peel after processing
• Strong flow for uniform, easy flow coating
• Good adhesion to glass and metal after UV curing
• Clear cured layer for glass wafer temporary fixing and protection
• No residue and no secondary contamination after removal

Applications

• Temporary fixing and protection of glass wafers during grinding
• Wafer thinning, polishing and dicing processes
• Temporary bonding of optical glass and lenses
• Temporary bonding of glass, jewelry and premium crafts
• Removable protective coating for precision glass parts

Operation Guide

1. Surface preparation: clean the wafer to remove oil, dust and contaminants.
2. Application: apply the adhesive by flow coating for even coverage.
3. UV curing: expose to UV light at 400 mJ/cm² until fully cured.
4. Processing: proceed with grinding, thinning, polishing or dicing.
5. Debonding: hydrolyze and wash off the cured adhesive in warm water.
6. Inspection: verify no residue remains on the wafer surface.

FAQ

Q1: What is this hydrolyzable UV adhesive mainly used for?
It is used for the temporary fixing and protection of glass wafers during grinding, thinning and other processing steps.

Q2: How is it removed?
It can be hydrolyzed and washed away in warm water, and it also comes off easily by ultrasonic cleaning.

Q3: Does it leave residue?
No. It peels off easily with no residue and no secondary contamination.

Q4: Which substrates does it bond to?
It provides good adhesion to glass and metal after curing.

Q5: What hardness and adhesion does it provide?
The cured layer has a Shore D hardness of 40 and an adhesion force of 14N.

Q6: What are the storage conditions and packaging?
Store at 8-28°C in the original sealed container. Shelf life is 12 months. Available in 250ml and 1kg packaging.
