Name: UV Sealing Adhesive | High-Viscosity Light Curing Glue for LCD Panels 3791
Brand: Shenzhen Super- curing Opto-Electronic CO., Ltd
SKU: 3791
Price: 3.99 USD
Availability: InStock

Python
import weasyprint

html_content = """<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8">
<style>
  @page {
    size: A4;
    margin: 15mm 15mm 15mm 15mm;
    background-color: #f8fafc;
  }

  *, *::before, *::after {
    box-sizing: border-box;
  }

  body {
    font-family: -apple-system, BlinkMacSystemFont, "Segoe UI", Roboto, "Helvetica Neue", Arial, sans-serif;
    color: #1e293b;
    margin: 0;
    padding: 0;
    font-size: 10pt;
    line-height: 1.5;
  }

  .header-card {
    background: linear-gradient(135deg, #1e3a8a 0%, #0284c7 100%);
    color: #ffffff;
    padding: 24px 28px;
    border-radius: 8px;
    margin-bottom: 20px;
  }

  .header-card h1 {
    margin: 0 0 6px 0;
    font-size: 20pt;
    font-weight: 700;
    letter-spacing: -0.5px;
  }

  .header-card .subtitle {
    font-size: 11pt;
    color: #e0f2fe;
    font-weight: 500;
    margin-bottom: 12px;
  }

  .header-card p {
    margin: 0;
    font-size: 9.5pt;
    color: #f0f9ff;
    line-height: 1.6;
  }

  .section-title {
    font-size: 12pt;
    font-weight: 700;
    color: #0f172a;
    border-left: 4px solid #0284c7;
    padding-left: 10px;
    margin-top: 20px;
    margin-bottom: 12px;
    text-transform: uppercase;
    letter-spacing: 0.5px;
  }

  .grid-table {
    width: 100%;
    border-collapse: collapse;
    margin-bottom: 20px;
  }

  .grid-table td {
    width: 50%;
    vertical-align: top;
    padding: 0 8px 0 0;
  }

  .grid-table td:last-child {
    padding: 0 0 0 8px;
  }

  .card {
    background: #ffffff;
    border: 1px solid #e2e8f0;
    border-radius: 6px;
    padding: 14px 16px;
    height: 100%;
  }

  .card ul {
    margin: 0;
    padding-left: 18px;
  }

  .card li {
    margin-bottom: 6px;
    color: #334155;
    font-size: 9.5pt;
  }

  .card li:last-child {
    margin-bottom: 0;
  }

  .spec-table {
    width: 100%;
    border-collapse: collapse;
    background: #ffffff;
    border: 1px solid #e2e8f0;
    border-radius: 6px;
    overflow: hidden;
    margin-bottom: 20px;
  }

  .spec-table th {
    background-color: #f1f5f9;
    color: #334155;
    font-weight: 600;
    text-align: left;
    padding: 8px 12px;
    font-size: 9.5pt;
    border-bottom: 1px solid #cbd5e1;
  }

  .spec-table td {
    padding: 8px 12px;
    border-bottom: 1px solid #f1f5f9;
    color: #0f172a;
    font-size: 9pt;
  }

  .spec-table tr:last-child td {
    border-bottom: none;
  }

  .spec-table tr:nth-child(even) {
    background-color: #f8fafc;
  }

  .faq-item {
    background: #ffffff;
    border: 1px solid #e2e8f0;
    border-radius: 6px;
    padding: 10px 14px;
    margin-bottom: 8px;
    page-break-inside: avoid;
  }

  .faq-q {
    font-weight: 700;
    color: #0369a1;
    margin-bottom: 4px;
    font-size: 9.5pt;
  }

  .faq-a {
    color: #334155;
    margin: 0;
    font-size: 9pt;
    line-height: 1.5;
  }

  .footer-text {
    margin-top: 15px;
    font-size: 8.5pt;
    color: #64748b;
    text-align: center;
    border-top: 1px solid #e2e8f0;
    padding-top: 10px;
  }
</style>
</head>
<body>

  <div class="header-card">
    <h1>3791 UV Sealing Adhesive</h1>
    <div class="subtitle">High-Viscosity & High-Hardness Light Curing Adhesive for Glass & Metal Bonding</div>
    <p>Our 3791 UV sealing adhesive is specifically formulated for high-reliability LCD panel sealing and glass substrate welding. Delivering superior damp-heat resistance, high hardness, and strong adhesion to glass and metal substrates, it ensures robust sealing performance under demanding operating conditions.</p>
  </div>

  <table class="grid-table">
    <tr>
      <td>
        <div class="card">
          <div style="font-weight: 700; color: #0f172a; margin-bottom: 8px; font-size: 10pt;">Key Features</div>
          <ul>
            <li><strong>High Viscosity & Hardness:</strong> Ensures stable gap filling without slumping and excellent mechanical strength.</li>
            <li><strong>Superior Damp-Heat Resistance:</strong> Maintains durable bonding integrity under high temperature and humidity environments.</li>
            <li><strong>Excellent Substrate Adhesion:</strong> Exceptional bond strength on glass and metal surfaces.</li>
            <li><strong>High Dielectric Strength:</strong> Exceptional electrical insulation (23 kV/mm) for delicate electronic displays.</li>
            <li><strong>Single-Component System:</strong> Solvent-free, ready-to-use formulation with fast UV curing.</li>
          </ul>
        </div>
      </td>
      <td>
        <div class="card">
          <div style="font-weight: 700; color: #0f172a; margin-bottom: 8px; font-size: 10pt;">Applications</div>
          <ul>
            <li><strong>LCD Panel Sealing:</strong> Edge sealing and welding of glass substrates in liquid crystal displays.</li>
            <li><strong>Glass-to-Metal Bonding:</strong> Structural bonding of electronic glass components to metal frames.</li>
            <li><strong>Display Module Assembly:</strong> Optical component sealing requiring high humidity resistance.</li>
            <li><strong>Precision Electronics Sealing:</strong> Protecting sensitive circuitry against moisture and environmental stress.</li>
          </ul>
        </div>
      </td>
    </tr>
  </table>

  <div class="section-title">Technical Specifications</div>
  <table class="spec-table">
    <thead>
      <tr>
        <th style="width: 45%;">Property / Parameter</th>
        <th style="width: 55%;">Specification Value</th>
      </tr>
    </thead>
    <tbody>
      <tr>
        <td><strong>Color / Appearance</strong></td>
        <td>Amber Transparent</td>
      </tr>
      <tr>
        <td><strong>Viscosity (25°C)</strong></td>
        <td>20,000 ± 2,000 mPa·s</td>
      </tr>
      <tr>
        <td><strong>Curing Condition</strong></td>
        <td>1000 mJ/cm² (UV Light)</td>
      </tr>
      <tr>
        <td><strong>Hardness (Shore D)</strong></td>
        <td>78</td>
      </tr>
      <tr>
        <td><strong>Glass Transition Temperature (Tg)</strong></td>
        <td>75°C</td>
      </tr>
      <tr>
        <td><strong>Dielectric Strength</strong></td>
        <td>23 kV/mm</td>
      </tr>
      <tr>
        <td><strong>Shelf Life</strong></td>
        <td>12 months at 8–28°C</td>
      </tr>
      <tr>
        <td><strong>Standard Packaging</strong></td>
        <td>1 kg / bottle</td>
      </tr>
    </tbody>
  </table>

  <div class="section-title">Packaging & Storage</div>
  <div class="card" style="margin-bottom: 20px;">
    <p style="margin: 0 0 6px 0;"><strong>Standard Packaging:</strong> 1 kg bottle. Store in a cool, dry place at 8–28°C away from direct sunlight and heat sources.</p>
    <p style="margin: 0;"><strong>Customization:</strong> Contact us for custom packaging sizes, OEM formulation, or specialized viscosity adjustments upon request.</p>
  </div>

  <div class="section-title">Frequently Asked Questions (FAQ)</div>

  <div class="faq-item">
    <div class="faq-q">Q1: How does 3791 UV adhesive cure and what is the curing energy required?</div>
    <div class="faq-a">A: It cures rapidly under UV light with a recommended cumulative UV energy of 1000 mJ/cm². Curing speed depends on UV intensity, wavelength, and layer thickness.</div>
  </div>

  <div class="faq-item">
    <div class="faq-q">Q2: What substrates can 3791 UV adhesive bond?</div>
    <div class="faq-a">A: It is specially designed for glass and metal substrates, offering strong adhesion for ITO glass, glass panels, aluminum, stainless steel, and alloy frames.</div>
  </div>

  <div class="faq-item">
    <div class="faq-q">Q3: Is this adhesive suitable for damp-heat and harsh environmental conditions?</div>
    <div class="faq-a">A: Yes. 3791 features outstanding damp-heat resistance and a high Tg (75°C), ensuring long-term reliability without delamination in warm and humid environments.</div>
  </div>

  <div class="faq-item">
    <div class="faq-q">Q4: What makes 3791 ideal for LCD panel welding and edge sealing?</div>
    <div class="faq-a">A: Its high viscosity (20,000 ± 2,000 mPa·s) prevents overflow during application, while high hardness (78 Shore D) and high dielectric strength (23 kV/mm) provide structural stability and electrical insulation.</div>
  </div>

  <div class="faq-item">
    <div class="faq-q">Q5: What are the storage requirements and shelf life?</div>
    <div class="faq-a">A: The product has a shelf life of 12 months when stored in its original tightly sealed container at 8–28°C in a cool, dry place away from light.</div>
  </div>

  <div class="faq-text footer-text">
    © 2026 Advanced Material Solutions. Technical data subject to change without notice.
  </div>

</body>
</html>
"""

with open("3791_UV_Sealing_Adhesive_TDS.html", "w", encoding="utf-8") as f:
    f.write(html_content)

weasyprint.HTML("3791_UV_Sealing_Adhesive_TDS.html").write_pdf("3791_UV_Sealing_Adhesive_TDS.pdf")
print("PDF generated successfully.")

代码输出
PDF generated successfully.

3791 UV Sealing Adhesive | High-Viscosity Light Curing Glue for LCD Panels

Product Description

Our 3791 UV sealing adhesive is specially formulated for high-reliability LCD panel sealing and glass substrate welding. Delivering low thermal shrinkage, high hardness, and superior damp-heat resistance, it provides strong adhesion for bonding glass to glass and glass to metals in precision electronic display applications.

Key Features

High viscosity & high hardness for gap filling, structural support, and dimensional stability
Superior damp-heat resistance for long-term reliable performance under humid and warm environments
Excellent adhesion to glass substrates and various metal components
High dielectric strength providing effective electrical insulation in electronic applications
Solvent-free single-component system, fast curing under UV light with no mixing required

Applications

LCD panel sealing: Glass substrate welding and perimeter sealing
Glass-to-metal bonding in electronic displays and optical components
Sealing of precision glass sub-assemblies and display modules
Other electronic devices requiring high insulation and damp-heat endurance

Technical Specifications

Property / Parameter	Specification Value
Color	Amber Transparent
Viscosity (25°C)	20,000 ± 2,000 mPa·s
Curing Condition	1000 mJ/cm²
Hardness (Shore D)	78
Glass Transition Temperature (Tg)	75°C
Dielectric Strength	23 kV/mm
Shelf Life	12 months at 8–28°C
Standard Packaging	1 kg

Packaging & Storage

Standard packaging: 1 kg bottle. Store at 8–28°C in a cool, dry place away from direct sunlight. Contact us for OEM formulation, custom viscosity, and packaging options upon request.

Frequently Asked Questions (FAQ)

Q1: How fast does the 3791 UV adhesive cure?

A: The adhesive cures rapidly under UV irradiation with a total energy requirement of 1000 mJ/cm². Actual curing speed depends on the UV lamp intensity, wavelength, and coating layer thickness.

Q2: What materials can this 3791 UV adhesive bond?

A: It is specially designed for bonding glass to glass and glass to metal substrates, including ITO glass, LCD panel substrates, stainless steel, and aluminum frames.

Q3: Is 3791 UV adhesive suitable for high-humidity environments?

A: Yes. It features outstanding damp-heat resistance and a high Tg (75°C), preventing degradation, yellowing, or delamination in warm and humid operating conditions.

Q4: What are the main benefits of its high viscosity (20,000 mPa·s)?

A: The high viscosity formulation prevents sagging and overflowing during application, allowing precise dispensing around LCD panel edges and tight seal gaps.

Q5: What are the storage requirements and shelf life?

A: Shelf life is 12 months when stored at 8–28°C in a cool, dry place away from direct sunlight. Keep the container tightly sealed after each use.

Q6: What packaging options are available?

A: Standard packaging is 1 kg. Custom packaging (such as syringes or smaller black bottles) can be provided upon request for automated production line compatibility.

All Reviews

Kumar

India Mar 12.2026

Helpful (55)

This UV adhesive, specifically designed for curing lenses, works well on our company's PC lenses and FR4 boards, and we are very satisfied.

H*r

New Zealand Mar 11.2026

Helpful (15)

UV glue bonded my acrylic products very well it's extremely strong and has excellent adhesion

Color:	Transparent / Fluorescent Trace Available	Viscosity (25 Deg C):	20,000 ± 2,000 MPa·s
Curing Condition:	1000 MJ/cm²	Hardness:	Shore D 78
Glass Transition Temperature:	Tg 75 Deg C	Shelf Life:	12 Months At 8-28 Deg C
Packaging:	1 Kg	Application:	Bonding Plastics To Metals, Injection Needle Hub Fixation
Highlight:	UV sealing adhesive for LCD panels , high-viscosity light curing glue , UV cure adhesive 3791

UV Sealing Adhesive | High-Viscosity Light Curing Glue for LCD Panels 3791
