Name: Transparent Silicone Fixing Adhesive | High-Viscosity UV Glue for LED Lens 3730
Brand: Shenzhen Super- curing Opto-Electronic CO., Ltd
SKU: 3730
Price: 3.99 USD
Availability: InStock

Python
import weasyprint

html_content = """<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8">
<style>
  @page {
    size: A4;
    margin: 15mm 15mm 15mm 15mm;
    background-color: #f8fafc;
  }

  *, *::before, *::after {
    box-sizing: border-box;
  }

  body {
    font-family: -apple-system, BlinkMacSystemFont, "Segoe UI", Roboto, "Helvetica Neue", Arial, sans-serif;
    color: #1e293b;
    margin: 0;
    padding: 0;
    font-size: 10pt;
    line-height: 1.5;
  }

  .header-card {
    background: linear-gradient(135deg, #1e3a8a 0%, #0284c7 100%);
    color: #ffffff;
    padding: 24px 28px;
    border-radius: 8px;
    margin-bottom: 20px;
  }

  .header-card h1 {
    margin: 0 0 6px 0;
    font-size: 20pt;
    font-weight: 700;
    letter-spacing: -0.5px;
  }

  .header-card .subtitle {
    font-size: 11pt;
    color: #e0f2fe;
    font-weight: 500;
    margin-bottom: 12px;
  }

  .header-card p {
    margin: 0;
    font-size: 9.5pt;
    color: #f0f9ff;
    line-height: 1.6;
  }

  .section-title {
    font-size: 12pt;
    font-weight: 700;
    color: #0f172a;
    border-left: 4px solid #0284c7;
    padding-left: 10px;
    margin-top: 20px;
    margin-bottom: 12px;
    text-transform: uppercase;
    letter-spacing: 0.5px;
  }

  .grid-table {
    width: 100%;
    border-collapse: collapse;
    margin-bottom: 20px;
  }

  .grid-table td {
    width: 50%;
    vertical-align: top;
    padding: 0 8px 0 0;
  }

  .grid-table td:last-child {
    padding: 0 0 0 8px;
  }

  .card {
    background: #ffffff;
    border: 1px solid #e2e8f0;
    border-radius: 6px;
    padding: 14px 16px;
    height: 100%;
  }

  .card ul {
    margin: 0;
    padding-left: 18px;
  }

  .card li {
    margin-bottom: 6px;
    color: #334155;
    font-size: 9.5pt;
  }

  .card li:last-child {
    margin-bottom: 0;
  }

  .spec-table {
    width: 100%;
    border-collapse: collapse;
    background: #ffffff;
    border: 1px solid #e2e8f0;
    border-radius: 6px;
    overflow: hidden;
    margin-bottom: 20px;
  }

  .spec-table th {
    background-color: #f1f5f9;
    color: #334155;
    font-weight: 600;
    text-align: left;
    padding: 8px 12px;
    font-size: 9.5pt;
    border-bottom: 1px solid #cbd5e1;
  }

  .spec-table td {
    padding: 8px 12px;
    border-bottom: 1px solid #f1f5f9;
    color: #0f172a;
    font-size: 9pt;
  }

  .spec-table tr:last-child td {
    border-bottom: none;
  }

  .spec-table tr:nth-child(even) {
    background-color: #f8fafc;
  }

  .faq-item {
    background: #ffffff;
    border: 1px solid #e2e8f0;
    border-radius: 6px;
    padding: 10px 14px;
    margin-bottom: 8px;
    page-break-inside: avoid;
  }

  .faq-q {
    font-weight: 700;
    color: #0369a1;
    margin-bottom: 4px;
    font-size: 9.5pt;
  }

  .faq-a {
    color: #334155;
    margin: 0;
    font-size: 9pt;
    line-height: 1.5;
  }

  .footer-text {
    margin-top: 15px;
    font-size: 8.5pt;
    color: #64748b;
    text-align: center;
    border-top: 1px solid #e2e8f0;
    padding-top: 10px;
  }
</style>
</head>
<body>

  <div class="header-card">
    <h1>3791 UV Sealing Adhesive</h1>
    <div class="subtitle">High-Viscosity & High-Hardness Light Curing Adhesive for Glass & Metal Bonding</div>
    <p>Our 3791 UV sealing adhesive is specifically formulated for high-reliability LCD panel sealing and glass substrate welding. Delivering superior damp-heat resistance, high hardness, and strong adhesion to glass and metal substrates, it ensures robust sealing performance under demanding operating conditions.</p>
  </div>

  <table class="grid-table">
    <tr>
      <td>
        <div class="card">
          <div style="font-weight: 700; color: #0f172a; margin-bottom: 8px; font-size: 10pt;">Key Features</div>
          <ul>
            <li><strong>High Viscosity & Hardness:</strong> Ensures stable gap filling without slumping and excellent mechanical strength.</li>
            <li><strong>Superior Damp-Heat Resistance:</strong> Maintains durable bonding integrity under high temperature and humidity environments.</li>
            <li><strong>Excellent Substrate Adhesion:</strong> Exceptional bond strength on glass and metal surfaces.</li>
            <li><strong>High Dielectric Strength:</strong> Exceptional electrical insulation (23 kV/mm) for delicate electronic displays.</li>
            <li><strong>Single-Component System:</strong> Solvent-free, ready-to-use formulation with fast UV curing.</li>
          </ul>
        </div>
      </td>
      <td>
        <div class="card">
          <div style="font-weight: 700; color: #0f172a; margin-bottom: 8px; font-size: 10pt;">Applications</div>
          <ul>
            <li><strong>LCD Panel Sealing:</strong> Edge sealing and welding of glass substrates in liquid crystal displays.</li>
            <li><strong>Glass-to-Metal Bonding:</strong> Structural bonding of electronic glass components to metal frames.</li>
            <li><strong>Display Module Assembly:</strong> Optical component sealing requiring high humidity resistance.</li>
            <li><strong>Precision Electronics Sealing:</strong> Protecting sensitive circuitry against moisture and environmental stress.</li>
          </ul>
        </div>
      </td>
    </tr>
  </table>

  <div class="section-title">Technical Specifications</div>
  <table class="spec-table">
    <thead>
      <tr>
        <th style="width: 45%;">Property / Parameter</th>
        <th style="width: 55%;">Specification Value</th>
      </tr>
    </thead>
    <tbody>
      <tr>
        <td><strong>Color / Appearance</strong></td>
        <td>Amber Transparent</td>
      </tr>
      <tr>
        <td><strong>Viscosity (25°C)</strong></td>
        <td>20,000 ± 2,000 mPa·s</td>
      </tr>
      <tr>
        <td><strong>Curing Condition</strong></td>
        <td>1000 mJ/cm² (UV Light)</td>
      </tr>
      <tr>
        <td><strong>Hardness (Shore D)</strong></td>
        <td>78</td>
      </tr>
      <tr>
        <td><strong>Glass Transition Temperature (Tg)</strong></td>
        <td>75°C</td>
      </tr>
      <tr>
        <td><strong>Dielectric Strength</strong></td>
        <td>23 kV/mm</td>
      </tr>
      <tr>
        <td><strong>Shelf Life</strong></td>
        <td>12 months at 8–28°C</td>
      </tr>
      <tr>
        <td><strong>Standard Packaging</strong></td>
        <td>1 kg / bottle</td>
      </tr>
    </tbody>
  </table>

  <div class="section-title">Packaging & Storage</div>
  <div class="card" style="margin-bottom: 20px;">
    <p style="margin: 0 0 6px 0;"><strong>Standard Packaging:</strong> 1 kg bottle. Store in a cool, dry place at 8–28°C away from direct sunlight and heat sources.</p>
    <p style="margin: 0;"><strong>Customization:</strong> Contact us for custom packaging sizes, OEM formulation, or specialized viscosity adjustments upon request.</p>
  </div>

  <div class="section-title">Frequently Asked Questions (FAQ)</div>

  <div class="faq-item">
    <div class="faq-q">Q1: How does 3791 UV adhesive cure and what is the curing energy required?</div>
    <div class="faq-a">A: It cures rapidly under UV light with a recommended cumulative UV energy of 1000 mJ/cm². Curing speed depends on UV intensity, wavelength, and layer thickness.</div>
  </div>

  <div class="faq-item">
    <div class="faq-q">Q2: What substrates can 3791 UV adhesive bond?</div>
    <div class="faq-a">A: It is specially designed for glass and metal substrates, offering strong adhesion for ITO glass, glass panels, aluminum, stainless steel, and alloy frames.</div>
  </div>

  <div class="faq-item">
    <div class="faq-q">Q3: Is this adhesive suitable for damp-heat and harsh environmental conditions?</div>
    <div class="faq-a">A: Yes. 3791 features outstanding damp-heat resistance and a high Tg (75°C), ensuring long-term reliability without delamination in warm and humid environments.</div>
  </div>

  <div class="faq-item">
    <div class="faq-q">Q4: What makes 3791 ideal for LCD panel welding and edge sealing?</div>
    <div class="faq-a">A: Its high viscosity (20,000 ± 2,000 mPa·s) prevents overflow during application, while high hardness (78 Shore D) and high dielectric strength (23 kV/mm) provide structural stability and electrical insulation.</div>
  </div>

  <div class="faq-item">
    <div class="faq-q">Q5: What are the storage requirements and shelf life?</div>
    <div class="faq-a">A: The product has a shelf life of 12 months when stored in its original tightly sealed container at 8–28°C in a cool, dry place away from light.</div>
  </div>

  <div class="faq-text footer-text">
    © 2026 Advanced Material Solutions. Technical data subject to change without notice.
  </div>

</body>
</html>
"""

with open("3791_UV_Sealing_Adhesive_TDS.html", "w", encoding="utf-8") as f:
    f.write(html_content)

weasyprint.HTML("3791_UV_Sealing_Adhesive_TDS.html").write_pdf("3791_UV_Sealing_Adhesive_TDS.pdf")
print("PDF generated successfully.")

代码输出
PDF generated successfully.

3730 Transparent Silicone Fixing Adhesive

Product Description

Our 3730 UV curing silicone fixing adhesive is specially engineered for optical lens bonding, TV backlight assemblies, and small component sealing. Featuring exceptional elasticity, high viscosity, superior weatherability, and strong impact resistance, it delivers long-term structural reliability under severe environmental stress.

Key Features

High Viscosity (40,000 mPa·s): Excellent gap-filling capability without sagging or slumping.
High Elasticity & Toughness: Absorbs mechanical shock, vibration, and thermal expansion stress.
Superior Weatherability: Outstanding resistance to UV degradation, aging, and temperature fluctuations.
Exceptional Mechanical Properties: Strong peel strength and durable adhesion to PMMA, PC, glass, and metals.
High Dielectric Strength: Reliable electrical insulation (25 kV/mm) for delicate electronic optics.

Applications

LED Backlight Lens Bonding: Precision positioning and fixing of optical lenses in TVs and displays.
Diffuse Reflection Light Bars: Bonding acrylic and PC lenses on linear LED strip modules.
Optical Components: Bonding side-lit lens arrays and specialized LED fixture modules.
Precision Component Sealing: Structural bonding and sealing of micro-electronic and optical sub-assemblies.

Technical Specifications

Property / Parameter	Specification Value
Color / Appearance	Amber Transparent
Viscosity (25°C)	40,000 ± 10,000 mPa·s
Curing Condition	1200 mJ/cm² (UV Light)
Hardness (Shore D)	75
Glass Transition Temperature (Tg)	27°C
Dielectric Strength	25 kV/mm
Shelf Life	12 months at 8–28°C
Standard Packaging	1 kg / bottle

Packaging & Storage

Standard Packaging: 1 kg bottle. Custom syringe packaging available for automated production lines upon request.

Storage & Handling: Store at 8–28°C in a cool, dry place away from direct sunlight. Keep containers tightly closed when not in use.

Frequently Asked Questions (FAQ)

Q1: How does 3730 silicone fixing adhesive cure?

A: It cures under UV irradiation with a recommended cumulative UV light dose of 1200 mJ/cm². Actual curing time depends on lamp power, UV intensity, and layer thickness.

Q2: Why is high viscosity (40,000 mPa·s) important for LED lens bonding?

A: The high viscosity ensures the adhesive stays precisely where dispensed without slumping or flowing into unintended optical zones before UV light curing.

Q3: What optical substrates can 3730 bond?

A: It offers outstanding adhesion to common optical plastics such as PMMA (acrylic) and PC (polycarbonate), as well as glass substrates and metal PCB heat sinks.

Q4: How does 3730 handle thermal and mechanical shock?

A: Thanks to its high elasticity, excellent peel strength, and Tg of 27°C, 3730 cushions impact and accommodates differential thermal expansion between plastic lenses and aluminum PCBs.

Q5: What is the shelf life and proper storage condition?

A: The product maintains a 12-month shelf life when stored in original unopened containers at 8–28°C in a dark, dry environment.

Q6: Can 3730 be supplied in custom packaging for automated dispensing lines?

A: Yes, while 1 kg bottles are standard, custom syringe cartridges can be provided for automated needle dispensing and high-precision assembly lines.

All Reviews

Kumar

India Mar 12.2026

Helpful (55)

This UV adhesive, specifically designed for curing lenses, works well on our company's PC lenses and FR4 boards, and we are very satisfied.

H*r

New Zealand Mar 11.2026

Helpful (15)

UV glue bonded my acrylic products very well it's extremely strong and has excellent adhesion

Color:	Transparent / Fluorescent Trace Available	Viscosity (25 Deg C):	40,000 ± 10,000 MPa·s
Curing Condition:	1200 MJ/cm²	Hardness:	Shore D 75
Glass Transition Temperature:	Tg 27 Deg C	Shelf Life:	12 Months At 8-28 Deg C
Packaging:	1 Kg	Application:	Bonding Plastics To Metals, Injection Needle Hub Fixation
Highlight:	transparent silicone fixing adhesive , high-viscosity UV glue , UV cure adhesive for LED lens
