UV Curing Electronic Conformal Coating Flexible Bending Resistant Fast Cure PE PET FFC Protection 3160

3160 UV Curing Electronic Conformal Coating is specially formulated for conformal coating of plastic materials such as FFC (flexible flat cable) and color row parallel wires. It features ultra-fast curing speed, flexibility and bending resistance, good adhesion to PE, PET, FFC and other materials, and remains transparent after curing with excellent moisture-proof, insulating and aging-resistant performance.

Key Features

• Ultra-fast curing speed at 300 mJ/cm² for efficient production
• Flexibility and bending resistance for reliable FFC and wire protection
• Good adhesion to PE, PET, FFC and various other materials
• Transparent after curing with moisture-proof, insulating and aging-resistant performance
• Low viscosity of 300±50 mPa.s for easy dispensing and coating
• High dielectric strength of 18 kV/mm for insulation protection

Applications

• FFC (flexible flat cable) conformal coating and protection
• Color row parallel wire coating and protection
• Conformal coating of plastic materials and components
• PE and PET substrate coating applications
• Moisture-proof and insulating protection of electronic assemblies

Technical Specifications

FAQ

Q1: What is the 3160 coating mainly used for?
3160 is a UV curing electronic conformal coating used for FFC (flexible flat cable), color row parallel wires and other plastic materials, providing moisture-proof, insulating and aging-resistant protection.

Q2: How fast does it cure?
3160 features ultra-fast curing speed at 300 mJ/cm², enabling high-efficiency production lines.

Q3: Is it flexible after curing?
Yes. The cured coating offers flexibility and bending resistance, making it suitable for FFC and wire applications that require repeated flexing.

Q4: What materials does it adhere to?
It provides good adhesion to PE, PET, FFC and various other plastic materials commonly used in electronic assemblies.

Q5: What does the coating look like after curing?
The coating remains transparent after curing while providing reliable moisture-proof, insulating and anti-aging protection.

Q6: What are the storage conditions?
Store at 8-28°C in the original sealed container. Shelf life is 12 months. Available in 250ml and 1kg packaging.
