High Clarity UV Light Curing Silicone Glue Description
"High clarity, elastic bonding." This high clarity UV light curing silicone glue is specially engineered for bonding LED lenses to acrylic and glass substrates. With strong adhesion, high elasticity and excellent weatherability, it keeps optical parts precisely fixed and delivers long-term structural reliability under demanding temperature and humidity conditions. Curing under UV light (1200 mJ/cm²) with a transparent, high-transmission bond line.
High Clarity UV Light Curing Silicone Glue Datasheet
| Model |
3730 UV light curing silicone glue |
Packaging specifications |
1 kg / bottle |
| Brand |
Super-curing |
Curing condition |
1200 mJ/cm² (UV light) |
| Application |
Acrylic and glass LED lens bonding |
Viscosity (25°C) |
40,000 ± 10,000 mPa·s |
| Adhesive material type |
UV curing silicone, plastics to metals |
Hardness |
Shore D 75 |
| Color |
High clarity transparent |
Glass transition temperature |
Tg 27°C |
| Shelf life |
12 months at 8-28°C |
Environmental protection level |
Superior |
Product Details Description
Product Applications
- Acrylic and glass LED lens bonding and fixing
- LED backlight lens positioning in TVs and displays
- Diffuse reflection light bars: acrylic and PC lenses on LED strip modules
- Optical lens and precision optical component bonding
- Plastics-to-metal structural bonding
- Injection needle hub fixation
- Precision electronic and optical sub-assembly sealing
- Side-lit lens arrays and specialized LED fixture modules
Precautions
- Surfaces must be clean, dry and free of oil, dust or mold release agents before applying.
- High viscosity keeps the adhesive in place; dispense precisely to avoid flowing into unintended optical zones.
- UV curing requires light to reach the adhesive; opaque or UV-blocking materials may not fully cure.
- Apply in a well-ventilated area. Avoid contact with skin and eyes; wear protective gloves and safety goggles.
- In case of skin or eye contact, rinse immediately with plenty of clean water and seek medical advice if irritation persists.
- Store sealed at 8-28°C in a cool, dark and dry place away from direct sunlight, and keep out of reach of children.
- Bond performance may vary with substrate, gap and UV intensity; please run a bonding test before mass production.
FAQ
Q1: How does this UV light curing silicone glue cure?
It cures under UV irradiation with a recommended cumulative UV dose of 1200 mJ/cm². Actual curing time depends on lamp power, UV intensity and layer thickness.
Q2: What substrates can it bond?
It offers strong adhesion to acrylic (PMMA) and glass, and also bonds PC (polycarbonate), other optical plastics and metals.
Q3: Is the cured bond optically clear?
Yes. It cures into a high clarity, transparent bond line with high light transmission, so it will not affect the optical performance of LED lenses.
Q4: Why is high viscosity important for LED lens bonding?
The high viscosity (40,000 ± 10,000 mPa·s) keeps the adhesive precisely where dispensed without slumping or flowing into unintended optical zones before curing.
Q5: What is the packaging and minimum order quantity?
Standard packaging is a 1 kg bottle, and the minimum order quantity is 10 pieces. Custom syringe packaging is available for automated lines.
Q6: How should it be stored and what is its shelf life?
Store sealed at 8-28°C in a cool, dark and dry place away from direct sunlight. Unopened shelf life is approximately 12 months.
