Ultra-Fast Cure Flexible UV Coating Glue Description
"Coat fast, flex forever." This ultra-fast cure flexible UV coating glue (3160) is a light yellow transparent, UV curing conformal coating specially formulated for ribbon cable, FFC (flexible flat cable) and wire harness insulation. It features ultra-fast curing speed, excellent flexibility and bending resistance, good adhesion to PE, PET, FFC and other plastic materials, and remains transparent after curing with reliable moisture-proof, insulating and aging-resistant performance.
Ultra-Fast Cure Flexible UV Coating Glue Datasheet
| Model |
3160 UV curing coating glue |
Packaging specifications |
250ml / 1kg |
| Brand |
Super-curing |
Cure condition |
300 mJ/cm² (UV) |
| Application |
FFC coating, color row parallel wire and plastic material protection |
Viscosity (25°C) |
300±50 mPa·s |
| Substrates |
PE, PET, FFC and plastic materials |
Hardness |
Shore D 65 |
| Color |
Light yellow transparent |
Dielectric strength |
18 kV/mm |
| Storage condition |
12 months (8-28°C) |
Glass transition temperature (Tg) |
60°C |
Product Details Description
Product Applications
- FFC (flexible flat cable) conformal coating and insulation
- Ribbon cable and color row parallel wire coating and protection
- Wire harness insulation for electronic assemblies
- Conformal coating of plastic materials and components
- PE and PET substrate coating applications
- Moisture-proof and insulating protection of flexible circuits
- Bending-resistant coating for repeatedly flexed parts
- Fast-cure coating for high-efficiency production lines
Precautions
- Surfaces must be clean, dry and free of oil, dust or release agents before coating.
- Apply a uniform coating thickness; avoid excess build-up around connectors and terminations.
- UV curing requires light to reach the coating; shadowed areas may need additional passes.
- Confirm adhesion and flexibility on the actual substrate before mass production.
- Apply in a well-ventilated area. Avoid contact with skin and eyes; wear protective gloves and safety goggles.
- In case of skin or eye contact, rinse immediately with plenty of clean water and seek medical advice if irritation persists.
- Store sealed at 8-28°C in a cool, dark and dry place away from direct sunlight and UV sources, and keep out of reach of children.
FAQ
Q1: What is this ultra-fast cure flexible UV coating glue mainly used for?
It is a UV curing coating glue for ribbon cable, FFC (flexible flat cable) and wire harness insulation, as well as conformal coating of plastic materials such as PE and PET.
Q2: How fast does it cure?
It features ultra-fast curing speed at 300 mJ/cm² of UV energy, enabling high-efficiency production lines.
Q3: Is the coating flexible after curing?
Yes. The cured coating offers excellent flexibility and bending resistance, making it suitable for FFC, ribbon cables and wires that require repeated flexing.
Q4: What materials does it adhere to?
It provides good adhesion to PE, PET, FFC and various other plastic materials commonly used in electronic assemblies.
Q5: What protection does the cured coating provide?
The coating remains transparent after curing while providing reliable moisture-proof, insulating and aging-resistant protection, with dielectric strength of 18 kV/mm.
Q6: What are the storage conditions and packaging?
Store sealed at 8-28°C in the original container, away from direct sunlight. Shelf life is 12 months, available in 250ml and 1kg packaging.
