High Performance UV CIPG Liquid Gasket Glue Description
"Formed in place, sealed for life." This high performance UV CIPG liquid gasket glue (3598) is a transparent blue, solvent-free, fast-curing UV adhesive designed for formed-in-place (FIP) and cured-in-place (CIP) gasket sealing in automotive electronics. It offers excellent compression rebound, outstanding heat, water and corrosion resistance, good flexibility and strong vibration resistance, as well as reliable high and low temperature performance for weatherproof sealing of electronic housings.
High Performance UV CIPG Liquid Gasket Glue Datasheet
| Model |
3598 UV curing liquid gasket glue |
Packaging specifications |
50g / 300g |
| Brand |
Super-curing |
Cure condition |
1000 mJ/cm² (UV) |
| Application |
Gasket sealing, weatherproof and vibration resistant sealing |
Viscosity (25°C) |
8500±1000 mPa·s |
| Process |
Formed-in-place (FIP) / cured-in-place (CIP) |
Hardness |
Shore A 55 |
| Color |
Transparent blue |
Tensile strength |
10 MPa |
| Storage condition |
12 months (8-28°C) |
Elongation at break |
80% |
| Thixotropy |
High |
Feature |
Solvent free |
Product Details Description
Product Applications
- Formed-in-place (FIP) gasket sealing for automotive electronics
- Cured-in-place (CIP) gasket sealing
- Weatherproof and waterproof sealing of electronic housings
- Vibration damping and compression sealing
- Dustproof sealing of controllers, sensors and connectors
- Sealing requiring heat, water and corrosion resistance
- Battery pack, ECU and lighting housing sealing
- Sealing of metal and plastic enclosures in harsh environments
Precautions
- Surfaces must be clean, dry and free of oil, dust or release agents before dispensing.
- Apply a uniform gasket bead; ensure the bead is continuous with no gaps or air pockets.
- UV curing requires light to reach the sealant; shadowed areas may need additional passes.
- Confirm compression and sealing performance on the actual enclosure before mass production.
- Apply in a well-ventilated area. Avoid contact with skin and eyes; wear protective gloves and safety goggles.
- In case of skin or eye contact, rinse immediately with plenty of clean water and seek medical advice if irritation persists.
- Store sealed at 8-28°C in a cool, dark and dry place away from direct sunlight and UV sources, and keep out of reach of children.
FAQ
Q1: What is this UV CIPG liquid gasket glue mainly used for?
It is a UV curing gasket glue for formed-in-place (FIP) and cured-in-place (CIP) sealing, used for weatherproof, waterproof and vibration resistant sealing of automotive electronic housings.
Q2: Is it solvent free and fast curing?
Yes. It is a solvent-free formulation that cures quickly under UV light at 1000 mJ/cm², suitable for high-efficiency production.
Q3: What sealing performance does it provide?
It offers excellent compression rebound together with outstanding heat, water and corrosion resistance for durable, weatherproof sealing.
Q4: Is it flexible and vibration resistant?
Yes. It has good flexibility and strong vibration resistance, and performs well across high and low temperatures.
Q5: Does it support FIP and CIP processes?
Yes. It is designed for both formed-in-place (FIP) and cured-in-place (CIP) gasket sealing processes.
Q6: What are the storage conditions and packaging?
Store sealed at 8-28°C in the original container. Shelf life is 12 months. Available in 50g and 300g packaging with export-grade carton.
